FGPF10N60UNDF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3 Full Pack
- Description: IGBT 600V 20A 42W TO-220F
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGPF10N60UNDF Specifications:
- MfrPart.: FGPF10N60UNDF
- Mfr: onsemi
- Description: IGBT 600V 20A 42W TO-220F
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 20 A
- Current-CollectorPulsed(Icm): 30 A
- Vce(on)(Max)@VgeIc: 2.45V @ 15V, 10A
- Power-Max: 42 W
- SwitchingEnergy: 150µJ (on), 50µJ (off)
- InputType: Standard
- GateCharge: 37 nC
- Td(on/off)@25°C: 8ns/52.2ns
- TestCondition: 400V, 10A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 37.7 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- FGPF10N60UNDF onsemi (ON), IGBT 600V 20A 42W TO-220F, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGPF10N60UNDF, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
