FGL60N100BNTDTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-264-3, TO-264AA
- Description: IGBT 1000V 60A 180W TO264
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGL60N100BNTDTU Specifications:
- MfrPart.: FGL60N100BNTDTU
- Mfr: onsemi
- Description: IGBT 1000V 60A 180W TO264
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Not For New Designs
- IGBTType: NPT and Trench
- Voltage-CollectorEmitterBreakdown(Max): 1000 V
- Current-Collector(Ic)(Max): 60 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 2.9V @ 15V, 60A
- Power-Max: 180 W
- SwitchingEnergy: -
- InputType: Standard
- GateCharge: 275 nC
- Td(on/off)@25°C: 140ns/630ns
- TestCondition: 600V, 60A, 51Ohm, 15V
- ReverseRecoveryTime(trr): 1.2 µs
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-264-3, TO-264AA
- FGL60N100BNTDTU onsemi (ON), IGBT 1000V 60A 180W TO264, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGL60N100BNTDTU, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
