FGL40N120ANDTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-264-3, TO-264AA
- Description: IGBT NPT 1200V 64A TO264-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGL40N120ANDTU Specifications:
- MfrPart.: FGL40N120ANDTU
- Mfr: onsemi
- Description: IGBT NPT 1200V 64A TO264-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Not For New Designs
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 64 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 3.2V @ 15V, 40A
- Power-Max: 500 W
- SwitchingEnergy: 2.3mJ (on), 1.1mJ (off)
- InputType: Standard
- GateCharge: 220 nC
- Td(on/off)@25°C: 15ns/110ns
- TestCondition: 600V, 40A, 5Ohm, 15V
- ReverseRecoveryTime(trr): 112 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-264-3, TO-264AA
- FGL40N120ANDTU onsemi (ON), IGBT NPT 1200V 64A TO264-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGL40N120ANDTU, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
