FGL12040WD Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-264-3, TO-264AA
- Description: IGBT TRENCH/FS 1200V 80A TO264-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGL12040WD Specifications:
- MfrPart.: FGL12040WD
- Mfr: onsemi
- Description: IGBT TRENCH/FS 1200V 80A TO264-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 100 A
- Vce(on)(Max)@VgeIc: 2.9V @ 15V, 40A
- Power-Max: 391 W
- SwitchingEnergy: 4.1mJ (on), 1mJ (off)
- InputType: Standard
- GateCharge: 226 nC
- Td(on/off)@25°C: 45ns/560ns
- TestCondition: 600V, 40A, 23Ohm, 15V
- ReverseRecoveryTime(trr): 71 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-264-3, TO-264AA
- FGL12040WD onsemi (ON), IGBT TRENCH/FS 1200V 80A TO264-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
