FGHL40T65MQD Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3 Variant
- Description: IGBT 650V 40A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGHL40T65MQD Specifications:
- MfrPart.: FGHL40T65MQD
- Mfr: onsemi
- Description: IGBT 650V 40A TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 1.8V @ 15V, 40A
- Power-Max: 238 W
- SwitchingEnergy: 860µJ (on), 520µJ (off)
- InputType: Standard
- GateCharge: 86 nC
- Td(on/off)@25°C: 22ns/109ns
- TestCondition: 400V, 40A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 33 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3 Variant
- FGHL40T65MQD onsemi (ON), IGBT 650V 40A TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
