FGHL40S65UQ Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 650V 40A
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGHL40S65UQ Specifications:
- MfrPart.: FGHL40S65UQ
- Mfr: onsemi
- Description: IGBT 650V 40A
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 1.7V @ 15V, 40A
- Power-Max: 231 W
- SwitchingEnergy: 1.76mJ (on), 362µJ (off)
- InputType: Standard
- GateCharge: 306 nC
- Td(on/off)@25°C: 32ns/260ns
- TestCondition: 400V, 40A, 6Ohm, 15V
- ReverseRecoveryTime(trr): 319 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- FGHL40S65UQ onsemi (ON), IGBT 650V 40A, Discrete Semiconductor Products~Transistors - IGBTs - Single
