FGH75T65UPD-F155 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: 650V,75A FIELD STOP TRENCH IGBT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGH75T65UPD-F155 Specifications:
- MfrPart.: FGH75T65UPD-F155
- Mfr: onsemi
- Description: 650V,75A FIELD STOP TRENCH IGBT
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Not For New Designs
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 150 A
- Current-CollectorPulsed(Icm): 225 A
- Vce(on)(Max)@VgeIc: 2.3V @ 15V, 75A
- Power-Max: 375 W
- SwitchingEnergy: 3.68mJ (on), 1.6mJ (off)
- InputType: Standard
- GateCharge: 68 nC
- Td(on/off)@25°C: 42ns/216ns
- TestCondition: 400V, 75A, 3Ohm, 15V
- ReverseRecoveryTime(trr): 85 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- FGH75T65UPD-F155 onsemi (ON), 650V,75A FIELD STOP TRENCH IGBT, Discrete Semiconductor Products~Transistors - IGBTs - Single
