FGH75T65SQDTL4 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-4
- Description: 650V FS4 TRENCH IGBT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGH75T65SQDTL4 Specifications:
- MfrPart.: FGH75T65SQDTL4
- Mfr: onsemi
- Description: 650V FS4 TRENCH IGBT
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 150 A
- Current-CollectorPulsed(Icm): 300 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 75A
- Power-Max: -
- SwitchingEnergy: 307µJ (on), 266µJ (off)
- InputType: Standard
- GateCharge: 128 nC
- Td(on/off)@25°C: 44ns/276ns
- TestCondition: 400V, 18.8A, 15Ohm, 15V
- ReverseRecoveryTime(trr): 76 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-4
- FGH75T65SQDTL4 onsemi (ON), 650V FS4 TRENCH IGBT, Discrete Semiconductor Products~Transistors - IGBTs - Single
