FGH75T65SQDNL4 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-4
- Description: 650V/75 FAST IGBT FSIII T
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGH75T65SQDNL4 Specifications:
- MfrPart.: FGH75T65SQDNL4
- Mfr: onsemi
- Description: 650V/75 FAST IGBT FSIII T
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 200 A
- Current-CollectorPulsed(Icm): 200 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 75A
- Power-Max: 375 W
- SwitchingEnergy: 1.25mJ (on), 1.26mJ (off)
- InputType: Standard
- GateCharge: 152 nC
- Td(on/off)@25°C: 44ns/208ns
- TestCondition: 400V, 75A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 134 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-4
- FGH75T65SQDNL4 onsemi (ON), 650V/75 FAST IGBT FSIII T, Discrete Semiconductor Products~Transistors - IGBTs - Single
