FGH60T65SQD-F155 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT TRENCH/FS 650V 120A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGH60T65SQD-F155 Specifications:
- MfrPart.: FGH60T65SQD-F155
- Mfr: onsemi
- Description: IGBT TRENCH/FS 650V 120A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 120 A
- Current-CollectorPulsed(Icm): 240 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 60A
- Power-Max: 333 W
- SwitchingEnergy: 227µJ (on), 100µJ (off)
- InputType: Standard
- GateCharge: 79 nC
- Td(on/off)@25°C: 20.8ns/102ns
- TestCondition: 400V, 15A, 4.7Ohm, 15V
- ReverseRecoveryTime(trr): 34.6 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- FGH60T65SQD-F155 onsemi (ON), IGBT TRENCH/FS 650V 120A TO247-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
