FGH40T100SMD-F155 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1000V 80A 333W TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGH40T100SMD-F155 Specifications:
- MfrPart.: FGH40T100SMD-F155
- Mfr: onsemi
- Description: IGBT 1000V 80A 333W TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1000 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 2.3V @ 15V, 40A
- Power-Max: 333 W
- SwitchingEnergy: 2.35mJ (on), 1.15mJ (off)
- InputType: Standard
- GateCharge: 398 nC
- Td(on/off)@25°C: 29ns/285ns
- TestCondition: 600V, 40A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 78 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- FGH40T100SMD-F155 onsemi (ON), IGBT 1000V 80A 333W TO247-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGH40T100SMD-F155, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
