FGH40N60SMDF-F085 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT FIELD STOP 600V 80A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGH40N60SMDF-F085 Specifications:
- MfrPart.: FGH40N60SMDF-F085
- Mfr: onsemi
- Description: IGBT FIELD STOP 600V 80A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: Automotive, AEC-Q101
- PartStatus: Obsolete
- IGBTType: Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 40A
- Power-Max: 349 W
- SwitchingEnergy: 1.3mJ (on), 260µJ (off)
- InputType: Standard
- GateCharge: 122 nC
- Td(on/off)@25°C: 18ns/110ns
- TestCondition: 400V, 40A, 6Ohm, 15V
- ReverseRecoveryTime(trr): 90 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- FGH40N60SMDF-F085 onsemi (ON), IGBT FIELD STOP 600V 80A TO247-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGH40N60SMDF-F085, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
