FGH30S130P Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1300V 60A 500W TO-247AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGH30S130P Specifications:
- MfrPart.: FGH30S130P
- Mfr: onsemi
- Description: IGBT 1300V 60A 500W TO-247AB
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1300 V
- Current-Collector(Ic)(Max): 60 A
- Current-CollectorPulsed(Icm): 90 A
- Vce(on)(Max)@VgeIc: 2.3V @ 15V, 30A
- Power-Max: 500 W
- SwitchingEnergy: -
- InputType: Standard
- GateCharge: 78 nC
- Td(on/off)@25°C: -
- TestCondition: -
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- FGH30S130P onsemi (ON), IGBT 1300V 60A 500W TO-247AB, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGH30S130P, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
