FGH25N120FTDS Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 50A 313W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGH25N120FTDS Specifications:
- MfrPart.: FGH25N120FTDS
- Mfr: onsemi
- Description: IGBT 1200V 50A 313W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube,Tube
- Series: -
- PartStatus: Last Time Buy
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 50 A
- Current-CollectorPulsed(Icm): 75 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 25A
- Power-Max: 313 W
- SwitchingEnergy: 1.42mJ (on), 1.16mJ (off)
- InputType: Standard
- GateCharge: 169 nC
- Td(on/off)@25°C: 26ns/151ns
- TestCondition: 600V, 25A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 535 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- FGH25N120FTDS onsemi (ON), IGBT 1200V 50A 313W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGH25N120FTDS, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
