FGD4536TM_SN00306 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Description: IGBT 360V 125W DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGD4536TM_SN00306 Specifications:
- MfrPart.: FGD4536TM_SN00306
- Mfr: onsemi
- Description: IGBT 360V 125W DPAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench
- Voltage-CollectorEmitterBreakdown(Max): 360 V
- Current-Collector(Ic)(Max): -
- Current-CollectorPulsed(Icm): 220 A
- Vce(on)(Max)@VgeIc: 1.8V @ 15V, 50A
- Power-Max: 125 W
- SwitchingEnergy: -
- InputType: Standard
- GateCharge: 47 nC
- Td(on/off)@25°C: -
- TestCondition: -
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- FGD4536TM_SN00306 onsemi (ON), IGBT 360V 125W DPAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
