FGD3N60UNDF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Description: IGBT 600V 6A 60W DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGD3N60UNDF Specifications:
- MfrPart.: FGD3N60UNDF
- Mfr: onsemi
- Description: IGBT 600V 6A 60W DPAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 6 A
- Current-CollectorPulsed(Icm): 9 A
- Vce(on)(Max)@VgeIc: 2.52V @ 15V, 3A
- Power-Max: 60 W
- SwitchingEnergy: 52µJ (on), 30µJ (off)
- InputType: Standard
- GateCharge: 1.6 nC
- Td(on/off)@25°C: 5.5ns/22ns
- TestCondition: 400V, 3A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 21 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- FGD3N60UNDF onsemi (ON), IGBT 600V 6A 60W DPAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
