FGB5N60UNDF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT NPT 600V 10A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGB5N60UNDF Specifications:
- MfrPart.: FGB5N60UNDF
- Mfr: onsemi
- Description: IGBT NPT 600V 10A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 10 A
- Current-CollectorPulsed(Icm): 15 A
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 5A
- Power-Max: 73.5 W
- SwitchingEnergy: 80µJ (on), 70µJ (off)
- InputType: Standard
- GateCharge: 12.1 nC
- Td(on/off)@25°C: 5.4ns/25.4ns
- TestCondition: 400V, 5A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 35 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- FGB5N60UNDF onsemi (ON), IGBT NPT 600V 10A D2PAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGB5N60UNDF, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
