FGB20N60SFD Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT 600V 40A 208W D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGB20N60SFD Specifications:
- MfrPart.: FGB20N60SFD
- Mfr: onsemi
- Description: IGBT 600V 40A 208W D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- IGBTType: Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 40 A
- Current-CollectorPulsed(Icm): 60 A
- Vce(on)(Max)@VgeIc: 2.8V @ 15V, 20A
- Power-Max: 208 W
- SwitchingEnergy: 370µJ (on), 160µJ (off)
- InputType: Standard
- GateCharge: 65 nC
- Td(on/off)@25°C: 13ns/90ns
- TestCondition: 400V, 20A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 34 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- FGB20N60SFD onsemi (ON), IGBT 600V 40A 208W D2PAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGB20N60SFD, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
