FGAF20S65AQ Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3 Full Pack
- Description: IGBT 650V 20A TO-3PF
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGAF20S65AQ Specifications:
- MfrPart.: FGAF20S65AQ
- Mfr: onsemi
- Description: IGBT 650V 20A TO-3PF
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 40 A
- Current-CollectorPulsed(Icm): 60 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 20A
- Power-Max: 75 W
- SwitchingEnergy: 345µJ (on), 95µJ (off)
- InputType: Standard
- GateCharge: 38 nC
- Td(on/off)@25°C: 18ns/102ns
- TestCondition: 400V, 10A, 23Ohm, 15V
- ReverseRecoveryTime(trr): 235 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3 Full Pack
- FGAF20S65AQ onsemi (ON), IGBT 650V 20A TO-3PF, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGAF20S65AQ, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
