FGA6530WDF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT 650V 60A 176W TO3PN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGA6530WDF Specifications:
- MfrPart.: FGA6530WDF
- Mfr: onsemi
- Description: IGBT 650V 60A 176W TO3PN
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 60 A
- Current-CollectorPulsed(Icm): 90 A
- Vce(on)(Max)@VgeIc: 2.2V @ 15V, 30A
- Power-Max: 176 W
- SwitchingEnergy: 960µJ (on), 162µJ (off)
- InputType: Standard
- GateCharge: 37.4 nC
- Td(on/off)@25°C: 12ns/42.4ns
- TestCondition: 400V, 30A, 6Ohm, 15V
- ReverseRecoveryTime(trr): 81 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- FGA6530WDF onsemi (ON), IGBT 650V 60A 176W TO3PN, Discrete Semiconductor Products~Transistors - IGBTs - Single
