FGA60N65SMD Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT, 650V, 60A, FIELD STOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGA60N65SMD Specifications:
- MfrPart.: FGA60N65SMD
- Mfr: onsemi
- Description: IGBT, 650V, 60A, FIELD STOP
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 120 A
- Current-CollectorPulsed(Icm): 180 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 60A
- Power-Max: 600 W
- SwitchingEnergy: 1.54mJ (on), 450µJ (off)
- InputType: Standard
- GateCharge: 189 nC
- Td(on/off)@25°C: 18ns/104ns
- TestCondition: 400V, 60A, 3Ohm, 15V
- ReverseRecoveryTime(trr): 47 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- FGA60N65SMD onsemi (ON), IGBT, 650V, 60A, FIELD STOP, Discrete Semiconductor Products~Transistors - IGBTs - Single
