FGA6065ADF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT TRENCH/FS 650V 120A TO3PN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGA6065ADF Specifications:
- MfrPart.: FGA6065ADF
- Mfr: onsemi
- Description: IGBT TRENCH/FS 650V 120A TO3PN
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 120 A
- Current-CollectorPulsed(Icm): 180 A
- Vce(on)(Max)@VgeIc: 2.3V @ 15V, 60A
- Power-Max: 306 W
- SwitchingEnergy: 2.46mJ (on), 520µJ (off)
- InputType: Standard
- GateCharge: 84 nC
- Td(on/off)@25°C: 25.6ns/71ns
- TestCondition: 400V, 60A, 6Ohm, 15V
- ReverseRecoveryTime(trr): 110 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- FGA6065ADF onsemi (ON), IGBT TRENCH/FS 650V 120A TO3PN, Discrete Semiconductor Products~Transistors - IGBTs - Single
