FGA50N60LS Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT 600V 100A 240W TO3P
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGA50N60LS Specifications:
- MfrPart.: FGA50N60LS
- Mfr: onsemi
- Description: IGBT 600V 100A 240W TO3P
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 100 A
- Current-CollectorPulsed(Icm): 150 A
- Vce(on)(Max)@VgeIc: 1.8V @ 15V, 50A
- Power-Max: 240 W
- SwitchingEnergy: 1.1mJ (on), 3.2mJ (off)
- InputType: Standard
- GateCharge: 167 nC
- Td(on/off)@25°C: 54ns/146ns
- TestCondition: 300V, 50A, 5.9Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- FGA50N60LS onsemi (ON), IGBT 600V 100A 240W TO3P, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGA50N60LS, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
