FGA4060ADF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT TRENCH/FS 600V 80A TO3PN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGA4060ADF Specifications:
- MfrPart.: FGA4060ADF
- Mfr: onsemi
- Description: IGBT TRENCH/FS 600V 80A TO3PN
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 2.3V @ 15V, 40A
- Power-Max: 238 W
- SwitchingEnergy: 1.37mJ (on), 250µJ (off)
- InputType: Standard
- GateCharge: 55.5 nC
- Td(on/off)@25°C: 16.8ns/54.4ns
- TestCondition: 400V, 40A, 6Ohm, 15V
- ReverseRecoveryTime(trr): 26 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- FGA4060ADF onsemi (ON), IGBT TRENCH/FS 600V 80A TO3PN, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGA4060ADF, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
onsemi (ON) Authorized Distributor | NHE is dedicated to providing first-quality, genuine onsemi components.
