FGA25N120FTD Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT 1200V 50A 313W TO3P
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGA25N120FTD Specifications:
- MfrPart.: FGA25N120FTD
- Mfr: onsemi
- Description: IGBT 1200V 50A 313W TO3P
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 50 A
- Current-CollectorPulsed(Icm): 75 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 25A
- Power-Max: 313 W
- SwitchingEnergy: 340µJ (on), 900µJ (off)
- InputType: Standard
- GateCharge: 160 nC
- Td(on/off)@25°C: 48ns/210ns
- TestCondition: 600V, 25A, 15Ohm, 15V
- ReverseRecoveryTime(trr): 770 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- FGA25N120FTD onsemi (ON), IGBT 1200V 50A 313W TO3P, Discrete Semiconductor Products~Transistors - IGBTs - Single
