FGA25N120ANTDTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT NPT/TRENCH 1200V 50A TO3P
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGA25N120ANTDTU Specifications:
- MfrPart.: FGA25N120ANTDTU
- Mfr: onsemi
- Description: IGBT NPT/TRENCH 1200V 50A TO3P
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: NPT and Trench
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 50 A
- Current-CollectorPulsed(Icm): 90 A
- Vce(on)(Max)@VgeIc: 2.65V @ 15V, 50A
- Power-Max: 312 W
- SwitchingEnergy: 4.1mJ (on), 960µJ (off)
- InputType: Standard
- GateCharge: 200 nC
- Td(on/off)@25°C: 50ns/190ns
- TestCondition: 600V, 25A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 350 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- FGA25N120ANTDTU onsemi (ON), IGBT NPT/TRENCH 1200V 50A TO3P, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGA25N120ANTDTU, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
