FGA20S125P-SN00336 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT 1250V 20A 250W TO-3PN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGA20S125P-SN00336 Specifications:
- MfrPart.: FGA20S125P-SN00336
- Mfr: onsemi
- Description: IGBT 1250V 20A 250W TO-3PN
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench
- Voltage-CollectorEmitterBreakdown(Max): 1250 V
- Current-Collector(Ic)(Max): 40 A
- Current-CollectorPulsed(Icm): 60 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 20A
- Power-Max: 250 W
- SwitchingEnergy: 740µJ (on), 500µJ (off)
- InputType: Standard
- GateCharge: 153 nC
- Td(on/off)@25°C: 10ns/400ns
- TestCondition: 600V, 20A, 10Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- FGA20S125P-SN00336 onsemi (ON), IGBT 1250V 20A 250W TO-3PN, Discrete Semiconductor Products~Transistors - IGBTs - Single
