FGA20S120M Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT 1200V 40A 348W TO3PN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGA20S120M Specifications:
- MfrPart.: FGA20S120M
- Mfr: onsemi
- Description: IGBT 1200V 40A 348W TO3PN
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 40 A
- Current-CollectorPulsed(Icm): 60 A
- Vce(on)(Max)@VgeIc: 1.85V @ 15V, 20A
- Power-Max: 348 W
- SwitchingEnergy: -
- InputType: Standard
- GateCharge: 208 nC
- Td(on/off)@25°C: -
- TestCondition: -
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- FGA20S120M onsemi (ON), IGBT 1200V 40A 348W TO3PN, Discrete Semiconductor Products~Transistors - IGBTs - Single
