FGA15N120FTDTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT 1200V 30A 220W TO3PN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FGA15N120FTDTU Specifications:
- MfrPart.: FGA15N120FTDTU
- Mfr: onsemi
- Description: IGBT 1200V 30A 220W TO3PN
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 30 A
- Current-CollectorPulsed(Icm): 45 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 15A
- Power-Max: 220 W
- SwitchingEnergy: -
- InputType: Standard
- GateCharge: 100 nC
- Td(on/off)@25°C: -
- TestCondition: -
- ReverseRecoveryTime(trr): 575 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- FGA15N120FTDTU onsemi (ON), IGBT 1200V 30A 220W TO3PN, Discrete Semiconductor Products~Transistors - IGBTs - Single
FGA15N120FTDTU, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
