FDZ3N513ZT Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 4-WLCSP (0.96x0.96)
- Description: MOSFET N-CH 30V 1.1A 4WLCSP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDZ3N513ZT Specifications:
- MfrPart.: FDZ3N513ZT
- Mfr: onsemi
- Description: MOSFET N-CH 30V 1.1A 4WLCSP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 1.1A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 3.2V, 4.5V
- RdsOn(Max)@IdVgs: 462mOhm @ 300mA, 4.5V
- Vgs(th)(Max)@Id: 1.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 1 nC @ 4.5 V
- Vgs(Max): +5.5V, -0.3V
- InputCapacitance(Ciss)(Max)@Vds: 85 pF @ 15 V
- FETFeature: Schottky Diode (Body)
- PowerDissipation(Max): 1W (Ta)
- OperatingTemperature: -55°C ~ 125°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 4-WLCSP (0.96x0.96)
- FDZ3N513ZT onsemi (ON), MOSFET N-CH 30V 1.1A 4WLCSP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
