FDWS9420-F085 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-PowerTDFN
- Description: POWER FIELD-EFFECT TRANSISTOR
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDWS9420-F085 Specifications:
- MfrPart.: FDWS9420-F085
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: POWER FIELD-EFFECT TRANSISTOR
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: 2 N-Channel (Dual)
- FETFeature: Standard
- DraintoSourceVoltage(Vdss): 40V
- Current-ContinuousDrain(Id)@25°C: 20A (Tc)
- RdsOn(Max)@IdVgs: 5.8mOhm @ 20A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 43nC @ 10V
- InputCapacitance(Ciss)(Max)@Vds: 2100pF @ 20V
- Power-Max: 75W
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-PowerTDFN
- FDWS9420-F085 onsemi (ON), POWER FIELD-EFFECT TRANSISTOR, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
FDWS9420-F085, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
