FDU3706 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: I-PAK
- Description: MOSFET N-CH 20V 14.7A/50A IPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDU3706 Specifications:
- MfrPart.: FDU3706
- Mfr: onsemi
- Description: MOSFET N-CH 20V 14.7A/50A IPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: PowerTrench®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 14.7A (Ta), 50A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 10V
- RdsOn(Max)@IdVgs: 9mOhm @ 16.2A, 10V
- Vgs(th)(Max)@Id: 1.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 23 nC @ 4.5 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 1882 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 3.8W (Ta), 44W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: I-PAK
- FDU3706 onsemi (ON), MOSFET N-CH 20V 14.7A/50A IPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FDU3706, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
