FDS7764A Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-SOIC
- Description: MOSFET N-CH 30V 15A 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDS7764A Specifications:
- MfrPart.: FDS7764A
- Mfr: onsemi
- Description: MOSFET N-CH 30V 15A 8SOIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: PowerTrench®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 15A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): -
- RdsOn(Max)@IdVgs: 7.5mOhm @ 15A, 4.5V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 40 nC @ 4.5 V
- Vgs(Max): -
- InputCapacitance(Ciss)(Max)@Vds: 3451 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-SOIC
- FDS7764A onsemi (ON), MOSFET N-CH 30V 15A 8SOIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
