FDS6688S Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-SOIC
- Description: MOSFET N-CH 30V 16A 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDS6688S Specifications:
- MfrPart.: FDS6688S
- Mfr: onsemi
- Description: MOSFET N-CH 30V 16A 8SOIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: PowerTrench®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 16A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 6mOhm @ 16A, 10V
- Vgs(th)(Max)@Id: 3V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 78 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3290 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-SOIC
- FDS6688S onsemi (ON), MOSFET N-CH 30V 16A 8SOIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FDS6688S, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
