FDS6685 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-SOIC
- Description: MOSFET P-CH 30V 8.8A 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDS6685 Specifications:
- MfrPart.: FDS6685
- Mfr: onsemi
- Description: MOSFET P-CH 30V 8.8A 8SOIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: PowerTrench®
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 8.8A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 20mOhm @ 8.8A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 24 nC @ 5 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 1604 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-SOIC
- FDS6685 onsemi (ON), MOSFET P-CH 30V 8.8A 8SOIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FDS6685, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
