FDPF3860TYDTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220F-3 (Y-Forming)
- Description: MOSFET N-CH 100V 20A TO220F-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDPF3860TYDTU Specifications:
- MfrPart.: FDPF3860TYDTU
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: MOSFET N-CH 100V 20A TO220F-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: PowerTrench®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 20A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 38.2mOhm @ 5.9A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 35 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1.8 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 33.8W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220F-3 (Y-Forming)
- FDPF3860TYDTU onsemi (ON), MOSFET N-CH 100V 20A TO220F-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FDPF3860TYDTU, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
