FDP2D9N12C Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220
- Description: PTNG 120V N-FET TO220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDP2D9N12C Specifications:
- MfrPart.: FDP2D9N12C
- Mfr: onsemi
- Description: PTNG 120V N-FET TO220
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: PowerTrench®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 120 V
- Current-ContinuousDrain(Id)@25°C: 18A (Ta), 210A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 6V, 10V
- RdsOn(Max)@IdVgs: 2.9mOhm @ 100A, 10V
- Vgs(th)(Max)@Id: 4V @ 686µA
- GateCharge(Qg)(Max)@Vgs: 109 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 8894 pF @ 60 V
- FETFeature: -
- PowerDissipation(Max): 2.4W (Ta), 333W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220
- FDP2D9N12C onsemi (ON), PTNG 120V N-FET TO220, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FDP2D9N12C, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
