FDN360P-NBGT003B Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23-3
- Description: MOSFET P-CH 30V 2A SOT23-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDN360P-NBGT003B Specifications:
- MfrPart.: FDN360P-NBGT003B
- Mfr: onsemi
- Description: MOSFET P-CH 30V 2A SOT23-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: PowerTrench®
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 2A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 80mOhm @ 2A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 9 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 298 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 500mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-23-3
- FDN360P-NBGT003B onsemi (ON), MOSFET P-CH 30V 2A SOT23-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
