FDMS86202 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-PQFN (5x6)
- Description: MOSFET N-CH 120V 13.5A POWER56
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDMS86202 Specifications:
- MfrPart.: FDMS86202
- Mfr: onsemi
- Description: MOSFET N-CH 120V 13.5A POWER56
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerTrench®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 120 V
- Current-ContinuousDrain(Id)@25°C: 13.5A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 6V, 10V
- RdsOn(Max)@IdVgs: 7.2mOhm @ 13.5A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 64 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 4250 pF @ 60 V
- FETFeature: -
- PowerDissipation(Max): 2.7W (Ta), 156W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-PQFN (5x6)
- FDMS86202 onsemi (ON), MOSFET N-CH 120V 13.5A POWER56, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FDMS86202, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
