FDMS2504SDC Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-PQFN (5x6)
- Description: MOSFET N-CH 25V 42A/49A DLCOOL56
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDMS2504SDC Specifications:
- MfrPart.: FDMS2504SDC
- Mfr: onsemi
- Description: MOSFET N-CH 25V 42A/49A DLCOOL56
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Dual Cool™, PowerTrench®, SyncFET™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 25 V
- Current-ContinuousDrain(Id)@25°C: 42A (Ta), 49A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 1.25mOhm @ 32A, 10V
- Vgs(th)(Max)@Id: 3V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 119 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 7770 pF @ 13 V
- FETFeature: -
- PowerDissipation(Max): 3.3W (Ta), 104W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-PQFN (5x6)
- FDMS2504SDC onsemi (ON), MOSFET N-CH 25V 42A/49A DLCOOL56, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
