FDMD8560L Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-PowerWDFN
- Description: MOSFET 2N-CH 46V 22A POWER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDMD8560L Specifications:
- MfrPart.: FDMD8560L
- Mfr: onsemi
- Description: MOSFET 2N-CH 46V 22A POWER
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerTrench®
- PartStatus: Active
- FETType: 2 N-Channel (Half Bridge)
- FETFeature: Standard
- DraintoSourceVoltage(Vdss): 60V
- Current-ContinuousDrain(Id)@25°C: 22A, 93A
- RdsOn(Max)@IdVgs: 3.2mOhm @ 22A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 128nC @ 10V
- InputCapacitance(Ciss)(Max)@Vds: 11130pF @ 30V
- Power-Max: 2.2W
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-PowerWDFN
- FDMD8560L onsemi (ON), MOSFET 2N-CH 46V 22A POWER, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
FDMD8560L, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
