FDMC4D9P20X8 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-PQFN (3.3x3.3)
- Description: MOSFET P-CH 20V 18A/75A 8PQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDMC4D9P20X8 Specifications:
- MfrPart.: FDMC4D9P20X8
- Mfr: onsemi
- Description: MOSFET P-CH 20V 18A/75A 8PQFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: PowerTrench®
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 18A (Ta), 75A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.8V, 4.5V
- RdsOn(Max)@IdVgs: 4.9mOhm @ 18A, 4.5V
- Vgs(th)(Max)@Id: 1.6V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 109 nC @ 4.5 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 10550 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 2.4W (Ta), 40W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-PQFN (3.3x3.3)
- FDMC4D9P20X8 onsemi (ON), MOSFET P-CH 20V 18A/75A 8PQFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
