FDMC2514SDC Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: Dual Cool ™ 33
- Description: MOSFET N-CH 25V 24A/40A DLCOOL33
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDMC2514SDC Specifications:
- MfrPart.: FDMC2514SDC
- Mfr: onsemi
- Description: MOSFET N-CH 25V 24A/40A DLCOOL33
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Dual Cool™, PowerTrench®, SyncFET™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 25 V
- Current-ContinuousDrain(Id)@25°C: 24A (Ta), 40A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 3.5mOhm @ 22.5A, 10V
- Vgs(th)(Max)@Id: 3V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 44 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2705 pF @ 13 V
- FETFeature: -
- PowerDissipation(Max): 3W (Ta), 60W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: Dual Cool ™ 33
- FDMC2514SDC onsemi (ON), MOSFET N-CH 25V 24A/40A DLCOOL33, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
