FDM2509NZ Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 6-UDFN Exposed Pad
- Description: MOSFET 2N-CH 20V 8.7A 2X5MLP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDM2509NZ Specifications:
- MfrPart.: FDM2509NZ
- Mfr: onsemi
- Description: MOSFET 2N-CH 20V 8.7A 2X5MLP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR)
- Series: PowerTrench®
- PartStatus: Obsolete
- FETType: 2 N-Channel (Dual)
- FETFeature: Logic Level Gate
- DraintoSourceVoltage(Vdss): 20V
- Current-ContinuousDrain(Id)@25°C: 8.7A
- RdsOn(Max)@IdVgs: 18mOhm @ 8.7A, 4.5V
- Vgs(th)(Max)@Id: 1.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 17nC @ 4.5V
- InputCapacitance(Ciss)(Max)@Vds: 1200pF @ 10V
- Power-Max: 800mW
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 6-UDFN Exposed Pad
- FDM2509NZ onsemi (ON), MOSFET 2N-CH 20V 8.7A 2X5MLP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
FDM2509NZ, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
