FDD86540 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252AA
- Description: MOSFET N-CH 60V 21.5A/50A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDD86540 Specifications:
- MfrPart.: FDD86540
- Mfr: onsemi
- Description: MOSFET N-CH 60V 21.5A/50A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerTrench®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 21.5A (Ta), 50A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 8V, 10V
- RdsOn(Max)@IdVgs: 4.1mOhm @ 21.5A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 90 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 6340 pF @ 30 V
- FETFeature: -
- PowerDissipation(Max): 3.1W (Ta), 127W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252AA
- FDD86540 onsemi (ON), MOSFET N-CH 60V 21.5A/50A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FDD86540, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
