FDD6680 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252AA
- Description: MOSFET N-CH 30V 12A/46A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDD6680 Specifications:
- MfrPart.: FDD6680
- Mfr: onsemi
- Description: MOSFET N-CH 30V 12A/46A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: PowerTrench®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 12A (Ta), 46A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 10mOhm @ 12A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 18 nC @ 5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1230 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 3.3W (Ta), 56W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252AA
- FDD6680 onsemi (ON), MOSFET N-CH 30V 12A/46A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FDD6680, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
