FDD4685 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252AA
- Description: MOSFET P-CH 40V 8.4A/32A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDD4685 Specifications:
- MfrPart.: FDD4685
- Mfr: onsemi
- Description: MOSFET P-CH 40V 8.4A/32A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerTrench®
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 8.4A (Ta), 32A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 27mOhm @ 8.4A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 27 nC @ 5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2380 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 69W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252AA
- FDD4685 onsemi (ON), MOSFET P-CH 40V 8.4A/32A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FDD4685, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
