FDD4685-F085P Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252AA
- Description: MOSFET P-CH 40V 32A TO252
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDD4685-F085P Specifications:
- MfrPart.: FDD4685-F085P
- Mfr: onsemi
- Description: MOSFET P-CH 40V 32A TO252
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101, PowerTrench®
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 32A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 27mOhm @ 8.4A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 27 nC @ 5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2380 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 83W (Tj)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252AA
- FDD4685-F085P onsemi (ON), MOSFET P-CH 40V 32A TO252, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FDD4685-F085P, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
