FDC699P_F077 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SuperSOT™-6 FLMP
- Description: MOSFET P-CH 20V 7A SUPERSOT6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDC699P_F077 Specifications:
- MfrPart.: FDC699P_F077
- Mfr: onsemi
- Description: MOSFET P-CH 20V 7A SUPERSOT6
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: PowerTrench®
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 7A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 22mOhm @ 7A, 4.5V
- Vgs(th)(Max)@Id: 1.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 38 nC @ 5 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 2640 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 2W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SuperSOT™-6 FLMP
- FDC699P_F077 onsemi (ON), MOSFET P-CH 20V 7A SUPERSOT6, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
