FDC697P_F077 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SuperSOT™-6 FLMP
- Description: MOSFET P-CH 20V 8A SUPERSOT6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDC697P_F077 Specifications:
- MfrPart.: FDC697P_F077
- Mfr: onsemi
- Description: MOSFET P-CH 20V 8A SUPERSOT6
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerTrench®
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 8A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.8V, 4.5V
- RdsOn(Max)@IdVgs: 20mOhm @ 8A, 4.5V
- Vgs(th)(Max)@Id: 1.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 55 nC @ 4.5 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 3524 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 2W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SuperSOT™-6 FLMP
- FDC697P_F077 onsemi (ON), MOSFET P-CH 20V 8A SUPERSOT6, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
